Ejon Y20L Store 3D Neon Sign Making Machine Maquina para Hacer Letras y Bordes Laterales

Product Categories
Tianjin Ejon Flying Science And Technology Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Ejon Y20L Store 3D Neon Sign Making Machine Maquina para Hacer Letras y Bordes Laterales

Place of Origin : Tianjin, China

Brand Name : EJON

Condition : New

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : Ordinary Product

Warranty of core components : 1 Year

Core Components : Motor, servo

Material / Metal Processed : ALLOY, Stainless steel, Galvanized steel, Aluminum plate,

Automation : Automatic

Warranty : 1 Year

Weight (KG) : 450

Key Selling Points : High Productivity

Applicable Industries : Printing Shops, Advertising Company, Construction works

Showroom Location : Egypt, Canada, Turkey, United States, Viet Nam, Philippines, Brazil, Pakistan, Russia, Spain, Thailand, Kenya, South Korea, Sri Lanka, Ukraine, Malaysia, Australia

Product name : Y20L channel letter bending machine

Function : Auto Feeding+bending+slotting

Voltage : 220V 50Hz 2.0Kw

File Format : Dxf.Plt.Ai

Package size : 1410*780*1600mm

Suitable material : Stainless steel, galvanized sheet and flat aluminum

Material thickness : 0.4-1.2mm

Min.Bending Angle : R6

Control system : 4 axis control system

Machine weight : 400Kg

Packaging Details : The export wooden box

Port : Tianjin

Supply Ability : 2000 Set/Sets per Year

Price : $9,000.00/sets 1-2 sets

Contact Now

Product Overview

Ejon Y20L 3d channel sign machine outdoor stainless steel sign backlit led machine
sign channel letter equipment
бортогибочный станок для букв,ماكينة الانحناء للحروف,dobladora de letras de canal,dobladora de letras 3d

Ejon Y20L Multifunctional Automatic Channel Letter Bending Machine is an updated model of Ejon Y13L, which increases the slotting trip from 13 cm to 20 cm, to meet the requirement of wide material processing. Y20L uses imported high strength plane cutter for slotting, can easily deal with various metal sheet plate, such as stainless steel, iron, aluminum plate, galvanized plate. It is very popular in Middle East, America and Russia, and widely used in advertising company for metal signs manufacturing, including seiko letters, resin letters, narrow edge letters, rimless letters, luminous letters, etc.

Main characteristic of hardware

1. Double ball screw matched with nylon gear transmission.
2. Slotting mechanism with air blowing and cooling function.

3. Feeding support controlled by air cylinder.

4. High strength alloy planer controlled by high power servo.

5. Ductile cast iron double blades bending structure.

6. Steel coupling plus specially treated bender.

7. Encoder of cast structure.

8. External USB connection plus one button start function.

9. Button board with voltage display function.

Main characteristic of software

1. Various processing methods can be switched at will for different materials and fonts. 2. The injection amount can be accurately calculated according to the injection process. 3. The software integrates material data of the plates to ensure the bending degree. 4. The software automatically optimizes nodes, without the need for customers to manually delete nodes. 5. One click to switch the use of different cutters for different materials.
6. Plate data is automatically saved without multiple adjustments. 7. Continuous processing mode can be selected for batch processing, which is convenient and fast. 8. For angles smaller than R6, the thinning function can be selected to meet the requirements of various fonts. 9. Default sharp angle slotting function ensures the matching degree of slotting angle.
FEATURES AT A GLANCE
The Material Pre-straightening Structure effectively corrects the deformation phenomenon that often occurs when the user uses the coil material, so that the material can be leveled, thus improving the overall processing quality.

Ejon Y20L Store 3D Neon Sign Making Machine Maquina para Hacer Letras y Bordes Laterales
Ejon Y20L Store 3D Neon Sign Making Machine Maquina para Hacer Letras y Bordes Laterales
FEEDING
Ejon Y20L Store 3D Neon Sign Making Machine Maquina para Hacer Letras y Bordes Laterales
SLOTTING
Ejon Y20L Store 3D Neon Sign Making Machine Maquina para Hacer Letras y Bordes Laterales
BENDING
PRODUCT SPECIFICATIONS
No
Item
Data
1
Power
2.0 kW
2
Material thickness
0.4~1.2 mm
3
Slotting trip
10~200 mm
4
Applicable material
metal sheet: stainless steel, galvanized plate, aluminum plate, iron
5
Control system
4 axis control system (2 axis servo control)
6
Slotting method
Plane cutter
7
Working space
2400 mm * 1100 mm * 1500 mm
8
File format
Dxf.Plt.Ai
9
Machine weight
400 kg
PRODUCT CONFIGURATION
Ejon Y20L Store 3D Neon Sign Making Machine Maquina para Hacer Letras y Bordes Laterales
Cast clamps can avoid scratching the material, meanwhile improving the feeding holding.
Ejon Y20L Store 3D Neon Sign Making Machine Maquina para Hacer Letras y Bordes Laterales
The encoder monitors the numerical change of the feeding length in real time, compensates the unqualified data, and ensures the feeding accuracy.
Ejon Y20L Store 3D Neon Sign Making Machine Maquina para Hacer Letras y Bordes Laterales
Punching needles are made of imported steel. The punching holes are smooth and burr-free.
Ejon Y20L Store 3D Neon Sign Making Machine Maquina para Hacer Letras y Bordes Laterales
The slotting mechanism adds a new air blowing and cooling function to extend the service life of the cutter while ensuring smooth slotting.
Ejon Y20L Store 3D Neon Sign Making Machine Maquina para Hacer Letras y Bordes Laterales
The high-power servo motor ensures the stability and consistency of the slotting, as well as the positioning accuracy and stability of the high-speed bending.
Ejon Y20L Store 3D Neon Sign Making Machine Maquina para Hacer Letras y Bordes Laterales
One button starting function makes the activation more convenient, easier and faster.
Sample Letters Show
Ejon Y20L Store 3D Neon Sign Making Machine Maquina para Hacer Letras y Bordes Laterales
Seiko letter
Ejon Y20L Store 3D Neon Sign Making Machine Maquina para Hacer Letras y Bordes Laterales
Resin letters
Ejon Y20L Store 3D Neon Sign Making Machine Maquina para Hacer Letras y Bordes Laterales
Narrow edge letters
Ejon Y20L Store 3D Neon Sign Making Machine Maquina para Hacer Letras y Bordes Laterales
Rimless letter
Ejon Y20L Store 3D Neon Sign Making Machine Maquina para Hacer Letras y Bordes Laterales
Luminous letters
Ejon Y20L Store 3D Neon Sign Making Machine Maquina para Hacer Letras y Bordes Laterales
Luminous letters
*** We also have the metal strips on sale, click here to tell us what you need***
